L1800 Revision A
Disassembly And Assembly Overview 36
Confidential
3.1.2 Tools
The following table indicates the tools recommended for use for disassembly,
reassembly and adjustment.
Note : All of the tools listed above are commercially available. EPSON provides the tools
listed with EPSON tool code.
3.1.3 Screws
The following table lists the screws used in this product. When disassembling and
reassembling the printer, refer to the following table and use the specified screws in the
specified positions.
Table 3-1. List of Tools
Tool Name Code
Phillips Screw Driver, No.1 1080530
Phillips Screw Driver, No.2 -
Flathead Screwdriver -
Tweezers -
Needle nose pliers -
Nipper -
Acetate tape 1003963
PF Tension Measuring Tool 1294120
Penlight -
Strong tape 1032813
Table 3-2. List of Screw Types
No. Name No. Name
1) C.B.P. M3x10 11) C.C. M3x4
2) C.B.S. M3x6 12) C.P.B. (P1) M1.7x5
3) C.B.S. (P2) M3x10 13) C.B.P. M2.6x5
4) C.B.P. M3x8 14) C.P. M3x4
5) C.B.S. M3x8 15) C.B.S. (P2) M3x8
6) C.B.S. (P4) M3x8 16) C.B.P. M2x8
7) C.B.P. M2.6x8 17) C.B. M3x6
8) C.B.S. (P4) M3x6 18) C.B.P. 3x12
9) C.B.P. M3x6 19) C.B. M3x4
10) C.B.S. M3x4
