Epson TM L90 Technical Reference Guide

108 Handling
Adhesive being removed with flat-blade screwdriver
WARNING:
Do not touch the area beyond the cutter blade edge. To do so may lead to injury
to your fingers.
Note:
Remove the accumulated adhesive behind the edge of the cutter blade. It is not necessary to polish it to
a mirror finish.
It is recommended not to use alcohol-based solvents. To do so may dissolve the adhesive and make
removing it even more difficult.
5. Insert the roll paper after removing the adhesive.
For the method of inserting the roll paper, refer to "Paper Loading Method" on page 55.
WARNING:
Be sure to remove your finger from inside the roll paper cover when you close it, or
you can get your finger caught inside.
6. Close the roll paper cover.

Epson TM L90 Specifications

General

Maximum resolution	203 x 203 DPI
Maximum roll diameter	90 mm
Supported paper width	37.5, 79 mm
RS-232 ports	1
Standard interfaces	RS-232
Connectivity technology	Wired
Country of origin	China
Dimensions (WxDxH)	140 x 203 x 148 mm
Flash memory	0.384 MB
Operating temperature (T-T)	5 - 45 °C
Pallet width	800 mm
Pallet height	2600 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	112 pc(s)
Quantity per pallet (UK)	168 pc(s)
Quantity per pallet layer	16 pc(s)
Quantity per pallet layer (UK)	24 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2560 g
Quantity per pack	1 pc(s)
