Epson TM L90 Technical Reference Guide

Setting/Checking Modes 77
TM-L90/TM-L90 Peeler Model Technical Reference Guide
Chapter 4
Setting/Checking Modes
4.1 Setting/Checking Modes of TM-L90 4** models, TM-L90 Peeler 39*
models
Besides the ordinary print mode, the printer has the following modes to set or check settings of
the printer.
❏ Self-test Mode
❏ NV Graphics Information Print Mode (page 79)
❏ Memory Switch Setting Mode (page 80)
❏ Hexadecimal Dump Mode (page 81)
The self-test mode or hexadecimal dumping mode is selected depending on the operation
performed when the power is turned on.
NV graphic information print mode and the memory switch setting mode are selected
depending on the FEED button operation performed during a self-test.
Close the roll paper cover, and turn on the printer while pressing the FEED button.
Self-test
Briefly press the FEED button. Hold down the FEED button.
Press the FEED button once briefly and
then hold it down.
Press the FEED button twice briefly and
then hold it down.
Open the roll paper cover, and turn on the printer while pressing the FEED
button, and then close the roll paper cover.
(For Peeler Models only) Load paper in the paper path, and then press the
FEED button.
Continuing the self-test
Mode selection guide
NV Graphics Information Print
Memory Switch Setting
Hexadecimal Dumping

Epson TM L90 Specifications

General

Maximum resolution	203 x 203 DPI
Maximum roll diameter	90 mm
Supported paper width	37.5, 79 mm
RS-232 ports	1
Standard interfaces	RS-232
Connectivity technology	Wired
Country of origin	China
Dimensions (WxDxH)	140 x 203 x 148 mm
Flash memory	0.384 MB
Operating temperature (T-T)	5 - 45 °C
Pallet width	800 mm
Pallet height	2600 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	112 pc(s)
Quantity per pallet (UK)	168 pc(s)
Quantity per pallet layer	16 pc(s)
Quantity per pallet layer (UK)	24 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2560 g
Quantity per pack	1 pc(s)
