Epson TM L90 Technical Reference Guide

50 Setup
2.8.2 Memory switches of TM-L90 Peeler Model
In the following tables, “✓” shows that the setting can be set by the utility or the setting mode.
Msw1
[Msw1-4], [Msw1-7], [Msw1-8]: Valid only for serial interface
[Msw1-5]: Valid only for parallel interface
[Msw1-7], [Msw1-8]: Not available for TM-L90 Peeler 39* models
Msw5 (only for 39* models)
[Msw5-1]: Valid only when the USB interface communication condition of the built-in USB is set to the Vendor-
defined class and the system configuration is set so that the USB driver can support the USB power-saving
function.
[Msw5-2]: Valid only when the receive buffer capacity is 4K bytes.
[Msw5-4]: Valid only for parallel interface
Msw Function Off On
Initial
setting
Msw Setting
utility
Msw Setting
Mode
1-1 Transmission of Power-on
notice
Disabled Enabled Off ✓✓
1-2 Receive buffer capacity 4K bytes 45 bytes Off ✓✓
1-3 BUSY condition Receive
buffer full or
Offline
Receive
buffer full
Off ✓✓
1-4 Data processing for receive
error
Replaced
with "?"
Ignored Off ✓✓
1-5 Automatic line feed Disabled Enabled Off ✓✓
1-6 (Reserved) Fixed to Off Off
1-7 #6 pin of RS-232 Not used Used for reset Off ✓✓
1-8 #25 pin of RS-232 Not used Used for reset Off ✓✓
Msw Function Off On
Initial
setting
Msw Setting
utility
Msw Setting
Mode
5-1 USB power-saving function Enabled Disabled Off ✓✓
5-2 Recovery conditions from
receive buffer BUSY
256 bytes free 138 bytes free Off ✓✓
5-3 Paper sensor to output paper
end signals
Enabled both
Roll paper
end sensor
and Roll
paper near-
end sensor
Disabled Off ✓
5-4 Error signal output Enabled Disabled Off ✓✓
5-5
to
5-8
(Reserved) - - Off

Epson TM L90 Specifications

General

Maximum resolution	203 x 203 DPI
Maximum roll diameter	90 mm
Supported paper width	37.5, 79 mm
RS-232 ports	1
Standard interfaces	RS-232
Connectivity technology	Wired
Country of origin	China
Dimensions (WxDxH)	140 x 203 x 148 mm
Flash memory	0.384 MB
Operating temperature (T-T)	5 - 45 °C
Pallet width	800 mm
Pallet height	2600 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	112 pc(s)
Quantity per pallet (UK)	168 pc(s)
Quantity per pallet layer	16 pc(s)
Quantity per pallet layer (UK)	24 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2560 g
Quantity per pack	1 pc(s)
