130 Appendix
Product Specifications
Product Specifications
TM-L90
4** models Other than 4** models
Print method Thermal line, 8 dots/mm 8 dots/mm (203 dpi 203 dpi)
Print width 80 mm (factory setting) or 38 to 70 mm can be set using a roll paper spacer
Cutting method Separated-blade scissor
Cut type Users can choose from the following two types.
❐ Full cut (cuts paper completely) (default setting)
❐ Partial cut (one point left uncut) is also available as a dealer option.
(Set by changing the position of the autocutter unit.)
Possible thickness
to be cut with a
manual cutter
100 m or less
Character sets 95 alphanumeric, 18 international
character sets, Extended graphics 128 47
pages (including user-defined page)
95 alphanumeric, 14 international character
sets, Extended graphics 128 11 pages
(including user-defined page)
Interface
(compatible)
RS-232C, Parallel, USB, Ethernet (10Base T/
100Base TX), Wireless LAN (IEEE802.11a/b/g/
n)
RS-232C, Parallel, USB, Ethernet (10Base T),
Wireless LAN (IEEE802.11b)
Buffer Receive buffer: 4 KB/45 bytes
User-defined buffer
Downloaded bit image: Approximately 12 KB
(common for all models)
User-defined characters: Approximately 11 KB
(for ANK/Multilingual model)
Approximately 15 KB
(for Japanese model)
Download graphics memory: 208 KB --
Macro buffer: 2 KB
Non-volatile graphics data buffer: 384 KB maximum
User NV memory: 192 KB maximum
Note) The combination of NV graphics data buffer and user NV memory is determined by
the memory switch.
Page mode area: 103 KB
D.K.D. function 2 drives
Power Supply Power supplied by AC adapter PS-180 (option)
Operating Voltage DC 24 V 7%
Current
consumption
Average: Approximately 1.8 A (Character
font A, -N, 36-character rolling pattern, full-
column printing)
Average: Approximately 1.7 A (Character
font A, -N, 36-character rolling pattern, full-
column printing)
Peak: Approximately 7.7 A
Standby: Approximately 0.1 A
