Appendix 129
TM-L90/TM-L90 Peeler Model Technical Reference Guide
3: Basic Serial Interface Settings [Baud rate set up]
2400 bps, 4800 bps, 9600 bps, 19200 bps
, 38400 bps, 57600
bps, 115200 bps
[Data bits / Handshaking / Parity set up]
8 bits / DTR/DSR / none
8 bits / DTR/DSR / even
8 bits / DTR/DSR / odd
8 bits / XON/XOFF / none
8 bits / XON/XOFF / even
8 bits / XON/XOFF / odd
7 bits / DTR/DSR / none
7 bits / DTR/DSR / even
7 bits / DTR/DSR / odd
7 bits / XON/XOFF / none
7 bits / XON/XOFF / even
7 bits / XON/XOFF / odd
4: Advanced Interface Settings [Buffer Capacity / Receive Error / Handshaking Operation
(Busy Condition)]
4 Kbytes / prints '?' / Off-line or Receive buffer full
4 Kbytes / prints '?' / Receive buffer full
4 Kbytes / ignore / Off-line or Receive buffer full
4 Kbytes / ignore / Receive buffer full
45 bytes / prints '?' / Off-line or Receive buffer full
45 bytes / prints '?' / Receive buffer full
45 bytes / ignore / Off-line or Receive buffer full
45 bytes / ignore / Receive buffer full
6: Interface Reset Signal [Serial #25 / Serial #6]
Disable / Disable
Disable / Enable
Enable / Disable
Enable / Enable
7: Paper Width 38 mm, 58 mm, 60 mm, 70 mm, 80 mm
8: Other settings 1 [Selection of the PAPER OUT LED status when a paper
near-end is detected]
On
, Off
[Recovery selection when paper layout error occurs]
DLE ENQ
DLE ENQ or Main cover open/close
DLE ENQ or press down PAPER FEED button
DLE ENQ or Main cover open/close or press down PAPER
FEED button
9: Other settings 2 [Select manual feed operation]
Paper feed to the print starting position
Paper feed to the peel position
11: Select label [Select automatic measurement of maximum length for
paper]
160 mm
, 300 mm
[Select moving to the print starting position when power is
turned on]
moves to starting position
does not move
