38 Setup
2.5.2 Setting Procedure
1. Turn off the power.
2. Pull the cover open lever, and open the roll paper cover.
3. Push the body case outward (in the direction of the 2 arrows) and remove the cutter cover.
4. Remove the single screw retaining the cutter unit and loosen the screw indicated by the
circle in the illustration below.
5. Lift the top of the cutter unit upward and remove it.
Remove this screw
Cutter unit
Loosen this screw
To Next Page
