Epson TM L90 Technical Reference Guide

Handling 117
TM-L90/TM-L90 Peeler Model Technical Reference Guide
❏ TM-L90 Peeler Model unrecoverable errors
Unrecoverable Errors
Error name Type of error Error LED flash code Recovery measure
R/W error in memory After R/W checking, the
printer does not work
correctly.
Impossible to
recover.
High voltage error The power supply voltage
is extremely high.
Impossible to
recover.
Low voltage error The power supply voltage
is extremely low.
Impossible to
recover.
CPU execution error The CPU executes an
incorrect address or I/F
board is not connected.
Impossible to
recover.
Internal circuit
connection error
Internal circuits are not
connected correctly.
Impossible to
recover.
UIB error An abnormal operation
occurs in UIB.
Impossible to
recover.
Approx.320 ms
Approx.5120 ms
LED ON
LED OFF
LED ON
LED OFF
LED ON
LED OFF
LED ON
LED OFF
Approx.2560 ms
LED ON
LED OFF
LED ON
LED OFF

Epson TM L90 Specifications

General

Maximum resolution	203 x 203 DPI
Maximum roll diameter	90 mm
Supported paper width	37.5, 79 mm
RS-232 ports	1
Standard interfaces	RS-232
Connectivity technology	Wired
Country of origin	China
Dimensions (WxDxH)	140 x 203 x 148 mm
Flash memory	0.384 MB
Operating temperature (T-T)	5 - 45 °C
Pallet width	800 mm
Pallet height	2600 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	112 pc(s)
Quantity per pallet (UK)	168 pc(s)
Quantity per pallet layer	16 pc(s)
Quantity per pallet layer (UK)	24 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2560 g
Quantity per pack	1 pc(s)
