Setup 43
TM-L90/TM-L90 Peeler Model Technical Reference Guide
DIP switch settings (Serial interface model)
bps: Indicates the number of bits transferred per second.
DIP switches 2 to 8 are for serial communication. Not used in parallel communication.
Note:
When you set the baud rate with the memory switch, you can set faster communication than with the DIP
switch. (Refer to "Memory Switch Settings" on page 44, "Error Code" on page 113)
In serial communication, intermittent printing* may occur. This is because when the communication
speed is low, a data transmission waiting state occurs frequently since the printing mechanism speed is
high. Increasing the communication speed may reduce this symptom.
* Intermittent printing: White streaks as large as one or two hairs appear horizontally in a printing result.
DIP switch settings (Parallel, USB, Ethernet model)
bps: Indicates the number of bits transferred per second.
DIP switches 2 to 8 are for serial communication. Not used in parallel communication.
SW No. Function ON OFF Initial Setting
1 Enable/disable Power
switch.
Switches power supply On/
Off using commands.
(Power switch is disabled.)
Power switch is used to
switch power On/Off.
OFF
2 Select for serial
communication condition.
Set using DIP switch 1-7, 1-8 Set using memory switches. ON
3 Handshake XON/XOFF DTR/DSR OFF
4 Bit length 7 bits 8 bits OFF
5 Parity check Yes No OFF
6 Parity type Even Odd OFF
7 Baud rate (bps) 7 8
ON ON :2400
OFF ON :4800
ON OFF :9600
OFF OFF :19200
OFF
8 OFF
SW No. Function ON OFF Initial Setting
1 Enable/disable Power
switch.
Switches power supply On/
Off using commands.
(Power switch is disabled.)
Power switch is used to
switch power On/Off.
OFF
2 Reserved Fixed to on -- ON
3 Reserved -- Fixed to off OFF
4 Reserved -- Fixed to off OFF
5 Reserved -- Fixed to off OFF
6 Reserved -- Fixed to off OFF
7 Reserved -- Fixed to off OFF
8 Reserved -- Fixed to off OFF
To Next Page
