Epson TM L90 Technical Reference Guide

Setup 57
TM-L90/TM-L90 Peeler Model Technical Reference Guide
7. As shown in the following figure, pull the end of the paper to the bottom of the square hole
above the manual cutter (label peeling sensor), and close the roll paper cover.
Note:
Matching the leading edge of the roll paper with the printed marks on the printer ensures that the fewest
possible labels are ejected automatically.
WARNING:
Do not close the roll paper cover with your finger still inside the roll paper cover.
Doing so may lead to injury.
8. A few labels are fed automatically and the PAPER OUT LED starts flashing.
9. Pass the backing paper that you pulled out to the other side of the peeler cover as shown in
the following figure, and close the peeler cover.
10. Press the FEED button. The printer automatically feeds the paper to the start position, and
the PAPER OUT LED goes off.
Note:
If the paper is not set properly when the FEED button is pressed, there may be label adhesive on the rollers
of the peeler. Peel off one label, and remove the adhesive from the roller by lifting it off with the adhesive
side of the label. For the cleaning method, refer to page 110. Paper setting with continuous issuing (not
using the peeler)

Epson TM L90 Specifications

General

Maximum resolution	203 x 203 DPI
Maximum roll diameter	90 mm
Supported paper width	37.5, 79 mm
RS-232 ports	1
Standard interfaces	RS-232
Connectivity technology	Wired
Country of origin	China
Dimensions (WxDxH)	140 x 203 x 148 mm
Flash memory	0.384 MB
Operating temperature (T-T)	5 - 45 °C
Pallet width	800 mm
Pallet height	2600 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	112 pc(s)
Quantity per pallet (UK)	168 pc(s)
Quantity per pallet layer	16 pc(s)
Quantity per pallet layer (UK)	24 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2560 g
Quantity per pack	1 pc(s)
