ESAB 100i - Page 56

100i / 200i / 300i / 400i
56 INSTALLATION Manual PN: 0560956430
Mounting Dimensions
10.90 in
[276.86 mm]
DPC-3000 Profile
4.00 in
[101.6 mm]
6.64in
[168.7mm]
11.00 in
[279.4 mm]
10.45 in
[265.4 mm]
.30 in
[7.62mm]
DPC-3000 Top
Art # A-09143
Preparation
1. Remove the screws securing the Cover Panel to the Module.
2. Carefully remove the cover from the module noting the attached wire harness that connects to J4. Remove the wire
harness and then set the cover to the side.
