Input Connections
1. Refer to the illustrations. Make the following input connections to the Arc Starter.
• Coolant Supply and Return Hoses (from External Cooler). Hoses and connectors are color-coded; Red for Return,
Green for Supply.
Coolant Supply and Return Hoses
(from power supply)
Art # A-12061
Supply
Return
To Next Page
