ESAB 100i - Page 85

100i / 200i / 300i / 400i
Manual PN: 0560956430 OPERATION 85
CCM Status Code
Group 2 -- Plasma Power Supply
246
Inverter 3B Input Volt-
age Error
Inverter Input Voltage fault; voltage out of range or missing phase at AC Input of In-
verter Module 3 Section B; Poor AC Power Quality; Defective W2 contactor; Loose or
open connection between input terminals and W2 contactor or contactor and input
of Inverter Section; Defective Inverter module
247
Inverter 1A Circuit
Fault Inverter Module 1 Section A detected a circuit fault; Damaged Inverter Module 1
248
Inverter 1B Circuit
Fault Inverter Module 1 Section B detected a circuit fault; Damaged Inverter Module 1
249
Inverter 2A Circuit
Fault Inverter Module 2 Section A detected a circuit fault; Damaged Inverter Module 2
250
Inverter 2B Circuit
Fault Inverter Module 2 Section B detected a circuit fault; Damaged Inverter Module 2
251
Inverter 3A Circuit
Fault Inverter Module 3 Section A detected a circuit fault; Damaged Inverter Module 3
252
Inverter 3B Circuit
Fault Inverter Module 3 Section B detected a circuit fault; Damaged Inverter Module 3
253 Inverter 1A Over Temp
Inverter Module 1 Section A is over temperature; Operating with side panels re-
moved, Check for restricted air flow, clogged radiator; Defective fan; If problem
persists replace inverter module.
254 Inverter 1B Over Temp
Inverter Module 1 Section B is over temperature; Operating with side panels re-
moved, Check for restricted air flow, clogged radiator; Defective fan; If problem
persists replace inverter module.
255 Inverter 2A Over Temp
Inverter Module 2 Section A is over temperature; Operating with side panels re-
moved, Check for restricted air flow, clogged radiator; Defective fan; If problem
persists replace inverter module.
256 Inverter 2B Over Temp
Inverter Module 2 Section B is over temperature; Operating with side panels re-
moved, Check for restricted air flow, clogged radiator; Defective fan; If problem
persists replace inverter module.
257 Inverter 3A Over Temp
Inverter Module 3 Section A is over temperature; Operating with side panels re-
moved, Check for restricted air flow, clogged radiator; Defective fan; If problem
persists replace inverter module.
258 Inverter 3B Over Temp
Inverter Module 3 Section B is over temperature; Operating with side panels re-
moved, Check for restricted air flow, clogged radiator; Defective fan; If problem
persists replace inverter module.
259
Inverter 1A Over Temp
Ambient
Inverter circuitry is over temperature likely cause is ambient greater than 40 deg
C; Reduce power supply cutting Duty Cycle; Reduce ambient air temperature; Add
auxiliary cooler.
260
Inverter 1B Over Temp
Ambient
Inverter circuitry is over temperature likely cause is ambient greater than 40 deg
C; Reduce power supply cutting Duty Cycle; Reduce ambient air temperature; Add
auxiliary cooler.
261
Inverter 2A Over Temp
Ambient
Inverter circuitry is over temperature likely cause is ambient greater than 40 deg
C; Reduce power supply cutting Duty Cycle; Reduce ambient air temperature; Add
auxiliary cooler.
262
Inverter 2B Over Temp
Ambient
Inverter circuitry is over temperature likely cause is ambient greater than 40 deg
C; Reduce power supply cutting Duty Cycle; Reduce ambient air temperature; Add
auxiliary cooler.
263
Inverter 3A Over Temp
Ambient
Inverter circuitry is over temperature likely cause is ambient greater than 40 deg
C; Reduce power supply cutting Duty Cycle; Reduce ambient air temperature; Add
auxiliary cooler.
