EW50 Industrial LTE Cellular Gateway
135
Specify Data Packing Parameters
Data Packing Configuration
Item
Value setting
Description
Data Buffer
Length
1. Optional setting
2. Default value is 0
Enter the data buffer length for the serial port.
Value Range: 0 ~ 1024.
Delimiter
Character 1
1. Optional setting
2. Default value is 0
Check the Enable box to activate the Delimiter character 1, and enter the Hex
code for it.
Value Range: 0x00 ~ 0xFF.
Delimiter
Character 2
1. Optional setting
2. Default value is 0
Check the Enable box to activate the Delimiter character 2, and enter the Hex
code for it.
Value Range: 0x00 ~ 0xFF.
Data Timeout
Transmit
1. Optional setting
2. Default value is 0
Enter the data timeout interval for transmitting serial data through the port.
By default, it is set to 0 and the timeout function is disabled.
Value Range: 0 ~ 1000ms.
Save
N/A
Click the Save button to save the configuration
Specify Remote TCP Server
Specify TCP Server Window
Item
Value setting
Description
To Remote Host
Required setting
Press Edit button to enter IP address or FQDN of the remote TCP server to
transmit serial data.
Remote Port
1. Required setting
2. Default value is 4001
Enter the TCP port number. This is the listening port of the remote TCP server.
Value Range: 1 ~ 65535.
Serial Port
SPort-0 is set by default
Apply the TCP server connection for a selected serial port. Up to 4 TCP servers
can be configured at the same time for each serial port.
