EW50 Industrial LTE Cellular Gateway
172
Similar to creating an IPsec VPN Tunnel for site/host to site/host scenario, when the Edit button is applied a
series of configuration screens will appear. They are Tunnel Configuration, Local & Remote Configuration,
Authentication, IKE Phase, IKE Proposal Definition, IPsec Phase, and IPsec Proposal Definition. Configure the
tunnel details for the gateway as a Dynamic VPN server.
Note: You can configure one Dynamic VPN server for each WAN interface.
Tunnel Configuration Window
Item
Value setting
Description
Tunnel
Unchecked by default
Check the Enable box to activate the Dynamic IPsec VPN tunnel.
Tunnel Name
1. Required setting
2. String format, any
text
Enter a tunnel name.
Value Range: 1 ~ 19 characters.
Interface
1. Required setting
2. WAN 1 is selected
by default
Select WAN interface on which IPsec tunnel is to be established.
Tunnel Scenario
1. Required setting
2. Dynamic VPN is
selected by default
The IPsec tunneling scenario is fixed to Dynamic VPN.
Operation Mode
1. Required setting
2. Always on is
selected by default
The available operation mode is Always On. Failover option is not available for
the Dynamic IPsec scenario.
Encapsulation
Protocol
1. Required setting
2. ESP is selected by
default
Select the Encapsulation Protocol from the dropdown box for this IPsec tunnel.
Available encapsulations are ESP and AH.
