EW50 Industrial LTE Cellular Gateway

Virtual Server Rule Configuration

Item

Value setting

Description

WAN Interface

1. Required setting

2. Default is ALL.

Define the selected interface to be the packet-entering interface of the

gateway.

If the packets to be filtered are coming from WAN-x then select WAN-x for this

field.

Select ALL for packets coming into the gateway from any interface.

Note: The available check boxes (WAN-1 ~ WAN-4) depend on the number of

WAN interfaces for the product.

Server IP

Required setting

This field is to specify the IP address of the interface selected in the WAN

Interface setting above.

Protocol

Required setting

When “ICMPv4” is selected, the protocol of packet filter rule is ICMPv4.

Apply Time Schedule to this rule, otherwise leave it as Always. (Refer to

Scheduling setting under Object Definition). Check Enable box to enable this

rule.

When “TCP” is selected, the protocol of packet filter rule is TCP.

Public Port is a predefined port from Well-known Service, and Private Port is

the same as Public Port number.

When Public Port is set as Single Port and a port number specified, Private Port

can be set as Single Port number.

When Public Port is set as Port Range and a port range specified, Private Port

can be set to Single Port or Port Range.

Value Range: 1 ~ 65535 for Public Port, Private Port.

When “UDP” is selected, the protocol of packet filter rule is UDP.
