CIRCUIT BOARD FUNCTIONS
The circuit boards are designed to be used
on several appliance models.
If the boards need replacing, the circuit
board conguration must be checked and
the suitable software must be loaded.
rigHt siDE viEw
1
3
2
4
Fig. 56
1. Noise filter
2. Terminal board
3. Activation board
4. Power supply
rigHt siDE viEw
1
2
3
Fig. 57
1. Water pump
2. Pressure reducer
3. Evomilk control board
rEar viEw
1
2
Fig. 58
1. Water inlet solenoid valve
2. Evomilk module
