Test Setup - Test Configurator, Timer, and System
MaxTester 109
FTFL/PT
PT
Note: Changing the payload type (PT) does not alter the signal structure; it only
modifies the OH value that is generated.
Payload Type and Code
Generated: Allows the selection of the payload signal type to be
generated either by selecting the payload type from the list or by
entering its code in hexadecimal (00 to FF).
Expected: Allows selecting the expected payload signal type.
Note: Codes not listed in the table are reserved for future standardization
(Reserved For International Standardization).
Payload type Hex Code
MSB
1234
LSB
5678
Reserved for International Standardization
a
00 0000 0000
Experimental mapping 01 0000 0001
Asynchronous CBR mapping 02 0000 0010
Bit Synchronous CBR mapping 03 0000 0011
ATM mapping 04 0000 0100
GFP mapping 05 0000 0101
Virtual Concatenation Signal 06 0000 0110
PCS Codeword Transparent Ethernet 07 0000 0111
FC-1200 into ODU2e 08 0000 1000
GFP mapping into extended OPU2 09 0000 1001
OC-3/STM-1 into ODU0 0A 0000 1010
OC-12/STM-4 into ODU0 0B 0000 1011
FC-100 into ODU0 0C 0000 1100
FC-200 into ODU1 0D 0000 1101
