Test Setup - Test Configurator, Timer, and System
110 MAX-800 Series
FTFL/PT
FC-400 into ODUflex 0E 0000 1110
FC-800 into ODUflex 0F 0000 1111
Bit Stream with Octet Timing mapping 10 0001 0000
Bit Stream Without Octet Timing mapping 11 0001 0001
IB SDR mapping into ODUflex 12 0001 0010
IB DDR mapping into ODUflex 13 0001 0011
IB QDR mapping into ODUflex 14 0001 0100
SDI mapping into OPU0 15 0001 0101
(1.485/1.001) Gbit/s SDI mapping into OPU1 16 0001 0110
1.485 Gbit/s SDI mapping in to OPU1 17 0001 0111
(2.970/1.001) Gbit/s SDI mapping into OPUflex 18 0001 1000
2.970 Gbit/s SDI mapping into OPUflex 19 0001 1001
SBCON/ESCON mapping into OPU0 1A 0001 1010
DVB_ASI mapping into OPU0 1B 0001 1011
FC-1600 mapping into OPUflex 1C 0001 1100
FlexE Client mapping into OPUflex 1D 0001 1101
FlexE aware (partial rate) mapping into OPUflex 1E 0001 1110
FC-3200 mapping into OPUflex 1F 0001 1111
ODU Multiplex with ODTUjk 20 0010 0000
ODU Multiplex with ODTUk.ts/ODTUjk 21 0010 0001
ODU multiplex with ODTUCn.ts 22 0010 0010
25GBASE-R mapping into OPUflex 30 0011 0000
200GBASE-R mapping into OPUflex 31 0011 0001
400GBASE-R mapping into OPUflex 32 0011 0010
Not Available
b
55 0101 0101
Reserved Codes for Proprietary Use
c
80 1000 0000
Payload type Hex Code
MSB
1234
LSB
5678
