Test Setup - Test Configurator, Timer, and System
MaxTester 111
FTFL/PT
Note: The Code field is automatically updated when the Payload Type is
changed and vice versa.
OPU-PLM, when selected, enables the OPU-PLM alarm analysis.
NULL Test Signal mapping FD 1111 1101
PRBS Test Signal mapping FE 1111 1110
a. Selecting Reserved for International Standardization will use the hexadecimal code 00 but, all codes
not listed in the previous table at the exception of those covered in notes b and c are reserved for future
standardization.
b. Selecting Not Available will use the hexadecimal code 55 but, 66 and FF are also Not Available payload
types.
c. Selecting Reserved Proprietary will use the hexadecimal code 80 but, all codes from 80 to 8F are
reserved proprietary payload types.
Payload type Hex Code
MSB
1234
LSB
5678
