Test Setup - Test Configurator, Timer, and System
116 MAX-800 Series
Interface
Physical Interface
For parallel interfaces, the following information is displayed for each
optical lane.
Optical Lane indicates the optical lane number.
Laser indicates the status of the laser: ON with the laser pictogram
(emitting an optical laser signal) or OFF.
TX Power (dBm) indicates, when supported, the transmit power level
of the optical lane/laser in dBm.
Wavelength (nm) indicates, when supported, the detected
wavelength.
RX Power (dBm) indicates, when supported, the current received
power level of the optical laser/lane in dBm.
Green: Power level in range.
Yellow: Power level out-of-range.
Red: Loss of signal or power level is close to damage.
Gray: Invalid operational range value or not available/supplied by the
transceiver.
For parallel interfaces, in the Test Configurator - Interface block, LO
and HI report respectively the current lowest and highest RX power
levels from any lane.
Min RX Power (dBm) indicates, when supported, the minimum
received power level of the optical laser/lane in dBm.
Max RX Power (dBm) indicates, when supported, the maximum
received power level of the optical laser/lane in dBm.
Optical Interface Optical Lane Number
100GE (4 Lanes) [103.125 Gbit/s] 0 through 3
