Test Setup - Test Configurator, Timer, and System
MaxTester 157
Services - Profile
The following table lists each component that may affect the
minimum frame size value.
Note: Sending traffic with frame size > 1518 in switched network may results in
losing theses frames.
EMIX button is available when EMIX frame size is selected. The
EMIX frame sequence is repeated continuously.
Quantity allows selecting 2 to 8 frame size values.
EMIX Frame Sizes allows setting the EMIX frame sizes. The
minimum frame size value is adjusted according to the frame
structure and components selected as shown in the above table.
Restore Default button reverts the quantity and EMIX frame sizes
to their default values.
Component Description
VLAN 4 bytes per VLAN (up to 2 VLAN)
MPLS 4 bytes per label (up to two labels)
UDP 8 bytes
TCP 20 bytes
Ethernet Header 14 bytes
LLC and SNAP Headers 8 bytes
IPv4 20 bytes
IPv6 40 bytes
Using DTS 4 bytes
