Test Functions
336 MAX-800 Series
OH BERT
OTUx and ODUx
Overhead group check boxes:
Layer Overhead Group
Number of
Bytes
OH Bytes Coordinate
Row Column
OTU GCC0 2 1 11,12
RES 2 1 13,14
ODU GCC1 2 4 1, 2
GCC2 2 4 3, 4
APS/PCC 4 4 5-8
PM&TCM 1 2 3
TCM ACT 1 2 4
FTFL
a
a. Only configurable when the test is not running. Once enabled, the FTFL configuration
and alarm generation and monitoring in the main test are not available for the top ODU
layer.
1214
EXP 2 3 13, 14
RES 8 2
4
1,2
9-14
TCM1
b
b. Only configurable when not enabled in the test and when the test is not running.
3 3 7, 8, 9
TCM2
b
3 3 4, 5, 6
TCM3
b
3 3 1, 2, 3
TCM4
b
3 2 11, 12, 13
TCM5
b
3 2 8, 9, 10
TCM6
b
3 2 5, 6, 7
