Selecting and Starting a Test
58 MAX-800 Series
Ethernet Test Applications
3d. Tap the protocol block
1
to configure the frame structure and its
parameters (refer to page 60). For RFC 2544, EtherBERT, and
Traffic Gen & Mon in Dual Port topology, there is a protocol block
for each port.
3e. Tap the test block
2
to configure the specific test settings (refer to
page 60).
3f. Tap the clock block
3
to configure the clock synchronization (refer
to Clock on page 88).
4. Tap the Timer tab to automatically start and/or stop the test at a given
time or for a specific duration (refer to Timer on page 193).
5. For additional test configurations refer to Test Functions on page 309.
6. Tap the Start button from the right navigation bar to start the test (refer
to Start/Stop|TX Button on page 402). The Summary result page will
be automatically displayed when the test is started from any Setup
configuration page. For additional results refer to Test Results on
page 201.
7. Depending on the test, when the test ends automatically or is manually
stopped, the generate report pop-up is displayed by default. If required,
tap Yes to generate a report of the test results and statistics (refer to
Report Button on page 392 for more information).
1. Not available with Smart Loopback, Through Mode, and Cable Test.
2. Not available with Traffic Gen & Mon and Through Mode.
3. Not available with
Dual Port
topology and when using an active copper SFP. However the clock is either set to
Internal
or
Auto
(1GE electrical).
