Test Setup - Test Configurator, Timer, and System
60 MAX-800 Series
Test Configurator for Ethernet test applications.
Timer, see page 193.
System, see page 192.
Block Subtab or Pop Up
Test Application
Page
a b c d e f g
ButtonModify Structure XXXXXXX 72
InterfaceFrequency XXXXXX - 105
Interface XXXXXXX112
Network XXXXXXX134
QSFP/SFP XXXXXX - 87
ProtocolMAC/IP/UDP XXXX - - - 121
Services - Global X------151
Services - Profile X------154
Streams - Global - - - X - - - 182
Streams - Profile - - - X - - - 184
Test Cable Test ------X85
EtherBERT and Unframed BERT - - X - - - - 93
EtherSAM - Burst X------ 97
EtherSAM - Global X------ 99
EtherSAM - Ramp X------103
RFC 2544 - Global -X-----139
RFC 2544 - Subtests -X-----142
Smart Loopback - - - - X - - 181
Clock Clock XXXXX - - 88
a. EtherSAM c. EtherBERT e. Smart Loopback g. Cable Test
b. RFC 2544 d. Traffic Gen & Mon f. Through Mode
