Test Setup - Test Configurator, Timer, and System
72 MAX-800 Series
Modify Structure Button
For Ethernet Test Applications
Note: For Dual Port topology each port is configurable individually.
Interface/Rate choices depend on the selected test and the rates
available on the unit. For Dual Port, both ports must be either 10GE and
less, or 100GE.
PHY Type allows selecting the transceiver PHY type:
For 100GE (4 Lanes) QSFP: LR4/ER4 (default), SR4, CWDM4, CLR4,
AOC, or Other. The PHY type when set to any except LR4/ER4, allows
enabling RS-FEC (see page 112); ensure both ends of the circuit have
the FEC enabled.
Primary Port / Secondary Port, available with Through Mode test
application, allows selecting the unit’s ports that are respectively used
as primary and secondary ports. The configuration of the network
configuration parameters will be available on the Primary Port only.
Test Interface/Rate
EtherSAM
RFC 2544
EtherBERT
Traffic Gen & Mon
Smart Loopback
100GE (4 Lanes) [103.125 Gbit/s]
10GE WAN
10GE LAN
1GE Optical
100M Optical
10/100/1000M Electrical
a
a. Used as a second port when the test application requires two ports; Ethernet
10/100/1000 Mbit/s electrical is supported when using an active copper SFP.
Through Mode 100GE (4 Lanes) [103.125 Gbit/s]
10GE LAN
1GE Optical
100M Optical
10/100/1000M Electrical
b
b. Ethernet 10/100/1000 Mbit/s electrical is supported when using an active copper
SFP and the RJ45 port on 860/860G/880 and using two active copper SFPs on
890/890Q.
Cable Test 10/100/1000M Electrical
