Test Setup - Test Configurator, Timer, and System
66 MAX-800 Series
Modify Structure Button
 Connector allows the selection of the unit’s port. For decoupled
topology on 890/890Q, TX and RX connectors are forced on the same
transceiver type.
Interface/Rate
Connector
860/860G/880 890/890Q
OTU4 - Port A1/A2 - QSFP28
OTU2 [10.709 Gbit/s]
OTU1 [2.666 Gbit/s]
OC-192 [9.953 Gbit/s]
OC-48 [2.488 Gbit/s]
OC-12[622.08Mbit/s]
OC-3 [155.520 Mbit/s]
OC-1 [51.840 Mbit/s]
STM-64 [9.953 Gbit/s]
STM-16 [2.488 Gbit/s]
STM-4 [622.080 Mbit/s]
STM-1 [155.520 Mbit/s]
STM-0 [51.840 Mbit/s]
Port 1 - SFP+
a
a. Port 2 is used with OC-192/STM-64 in Decoupled (TX≠RX) mode.
Port B1/B2 - SFP28
STS-3e [155.520 Mbit/s]
STS-1e [51.840 Mbit/s]
STM-1e [155.520 Mbit/s]
STM-0e [51.840 Mbit/s]
BNC -
DS1 [1.544 Mbit/s] Bantam
RJ48C
-
E1 [2.048 Mbit/s] Bantam
BNC
RJ48C
-
DS3[44.736Mbit/s]
E3 [34.368 Mbit/s]
E4 [139.264 Mbit/s]
BNC -
