BERT and Unframed BERT
TX Pattern/RX Pattern sets respectively the TX and RX test pattern.
100G Interfaces:
Interfaces up to 10G:
Test Framing Pattern
OTN BERT Framed PRBS9, PRBS15, PRBS20, PRBS23, PRBS31 (default), Null Client, and
User Pattern.
Unframed PRBS9, PRBS11
a
, PRBS15, PRBS20
a
, PRBS23, PRBS31 (default)
a. Not available with OTU4 - 4 Unframed Physical Lanes.
EtherBERT Unframed PRBS9, PRBS11
b
, PRBS15, PRBS20
b
, PRBS23, PRBS31 (default)
b. Not available with 100GE - 4 Unframed CAUI-4.
Pattern DS0, E0 DS1 DS3, E1 E3, E4 SONET/SDH OTN
0000, 1010, 1100, 1111, 1in8, 1in16, 2in8 XXX X X -
3in24 XXXX (E3 only) - -
T1 DALY, 55 OCTET, Multi-Pattern -X- - - -
PRBS9 XXX X X X
PRBS11 X
a
a. Default value.
XX X X
PRBS15 -XX
a
XX
b
b. Default value for VT1.5/TU-11/TU-12.
X
PRBS20, User Pattern XXX X X X
PRBS23 -XX X
a
X
c
c. Default value for HOP and all other SONET/SDH concatenations from STS-1/AU-3/AU-4/TU-3 up to
STS-48c/AU-4-16c.
X
PRBS31 -XX X X
d
d. Default value for STS-192c/AU-4-64c.
X
a
QRSS -X
a
-- --
Null Client --- - - X
