IN1806 and IN1808 Series Scaling Presentation Switchers • SIS Configuration and Control 60
X5!
= Video signal status
0 = Video, TMDS, or DP signal not detected
1 = Video, TMDS, or DP signal detected
X5&
= Remote port number
1 = Remote port (3-pole captive screw)
7 = Universal asynchronous receiver-transmitter (UART)
on DTP Input 7 (IN1808 Series only)
8 = Universal asynchronous receiver-transmitter (UART)
on DTP Input 8 (IN1808 Series only)
9 = UART on DTP/HDBT Output 1B
X5*
= Baud rate, RS-232 port
300, 600, 1200, 1800, 2400, 3600, 4800, 7200, 9600
(default), 14400, 19200, 28800, 38400, 57600, or
115200
X5(
= Parity
Odd, Even, None (default), Mark, Space
Only the first letter is required.
X6)
= Data bits
7 or 8 (default)
X6!
= Stop bits
1 (default) or 2
X6@
= Power Save mode
0 = Full power mode (default)
1 = Lowest power state — TP remote power and over
TP functions are disabled.
2 = Low power state — Over TP and TP remote power
are enabled.
X6#
= Screen saver status
0 = Active input detected, timer not running
1 = No active input, timer running, output sync still active
2 = No active input, timer expired, output sync disabled
X6$
= Port timeout Set time in increments of 10 seconds before the port
connection times out.
1 (10 seconds) through 65000 (650,000 seconds)
Default = 30 (300 seconds)
X6%
= Start point for UART ports Start point for UART ports:
Rear panel RS-232 =
X6%
TP IN 7 =
X6%
+ 1 (IN1808 Series only)
TP IN 8 =
X6%
+ 2 (IN1808 Series only)
TP OUT 1B =
X6%
+ 3
Default = 2000, meaning:
IN7 = 2001
IN8 = 2002
TP OUT1B = 2003
X6^
= DTP remote power
0 = No remote power (default)
1 = DTP — 12 VDC
2 = DTP2 — 48 VDC
X6&
= Twisted Pair format
0 = DTP format (default)
1 = XTP format
2 = HDBaseT format (supported on output only)
X6(
= Hot plug change or detection
0 = A sink has been removed (HPD deasserted).
1 = A new sink has been connected (HPD asserted).
X7)
= Key effect variable
0 = Transparency (available only when
X7@
= 1)
1 = Red of RGB key (available only when
X7@
= 2)
2 = Green of RGB key (available only when
X7@
= 2)
3 = Blue of RGB key (available only when
X7@
= 2)
4 = Level key
X7!
= Key effect setting
0 through 255
