IN1806 and IN1808 Series Scaling Presentation Switchers • SIS Configuration and Control 72
Command ASCII Command
(Host to Scaler)
Response
(Scaler to Host)
Additional Description
Logos (continued)
Logo Key Effect
Disabled
E X4#
*0 LKEF
}
Lkef
X4#
*0
]
Disable key effect for logo
X4#
.
Transparency
E X4#
*1 LKEF
}
Lkef
X4#
*1
]
Enable transparency for logo
X4#
RGB Key
E X4#
*2 LKEF
}
Lkef
X4#
*2
]
Enable RGB key for logo
X4#
.
Level Key
E X4#
*3 LKEF
}
Lkef
X4#
*3
]
Enable Level key for logo
X4#
.
Alpha Key
E X4#
*4 LKEF
}
Lkef
X4#
*4
]
Enable Alpha key for logo
X4#
.
View setting
E X4#
LKEF
} X7@]
Verbose modes 2 and 3:
Lkef
X4#
*
X7@]
View the current key effect (
X7@
) for logo
X4#
.
Logo Key Effect Level
Specific value
E X4#
*
X7)
*
X7!
*LKEY
}
Lkey
X4#
*
X7)
*
X7!]
Set the level for key effect variable
X7)
to
X7!
for logo
X4#
.
View setting
EX4#
*
X7)
LKEY
} X7!]
View level
X7!
set for key effect variable
X7)
for logo
X4#
.
KEY:
X1^
= Horizontal or vertical position (shift)
The position is ± the horizontal or vertical position of the highest output
resolution.
• Response is five digits, padded with zeros and preceded by + or –.
• The logo vertical position allows up to ± 2400.
X4#
= User logo number
1 through 16. The response is three digits padded with leading zeros.
101 = No signal, screen saver user logo or image is displayed.
201 = User HDCP logo displayed
X7)
= Key effect variable 0 = Transparency (available only when
X7@
= 1)
1 = Red of RGB key (available only when
X7@
= 2)
2 = Green of RGB key (available only when
X7@
= 2)
3 = Blue of RGB key (available only when
X7@
= 2)
4 = Level key (available only when
X7@
= 3)
X7!
= Key effect setting
0 through 255
X7@
= Key effect
0 = Disable, 1 = Transparency, 2 = RGB key, 3 = Level key,
4 = Alpha key
