IN1806 and IN1808 Series Scaling Presentation Switchers • SIS Configuration and Control 73
Command ASCII Command
(Host to Scaler)
Response
(Scaler to Host)
Additional Description
Presets
Input Presets
Values Saved in Input Presets
Preset Name H Image Position
Film Mode Detection V Image Position
Contrast H Image Size
Brightness V Image Size
Detail
Recall preset
2*
X2^
. 2Rpr
X2^]
Recall input preset
X2^
for the selected
input.
Save preset
2*
X2^
, 2Spr
X2^]
Save input preset
X2^
for the selected
input.
Delete preset
E
X 2*
X2^
PRST
}
PrstX2*
X2^]
Clear input preset
X2^
and set its name
to [unassigned].
Input Preset Name
Write preset name
E
2*
X2^
,
X1$
PNAM
}
Pnam2*
X2^
,
X1$]
Set the name of input preset
X2^
to
X1$
.
View preset name
E
2*
X2^
PNAM
} X1$]
View the name (
X1$
) of input preset
X2^
.
NOTE: Unsaved input presets are shown as [unassigned]. To restore a default input preset name (with the format
Input•Preset•nnn with leading zeros), enter a single space character for
X1$
. These entries are valid only for previously
saved presets.
Auto Memories
Enable
EX!
*1AMEM
}
Amem
X!
*1
]
Set Auto Memory to On (default state)
for input
X!
. Settings are automatically
stored as presets. Previous settings for
the incoming signal are recalled.
Disable
EX!
*0AMEM
}
Amem
X!
*0
]
Set Auto Memory to Off for input
X!
.
Manual recall of input presets is required
to configure the input.
View setting
EX!
AMEM
} X1) ]
Verbose modes 2 and 3:
Amem
X!
*
X1) ]
View current Auto Memory status
X1)
for input
X!
.
KEY:
X!
= Input selection
1 = DisplayPort input 1
2-6 = HDMI or DVI input 2, 3, 4, 5, or 6
7-8 = DTP2/XTP input 7 or 8 (IN1808 Series only)
9 = Aux audio input
X1)
= On or off, enable or disable
0 = Off or disabled
1 = On or enabled
X1$
= Preset name (text label) Up to 32 characters, excluding , (comma) ,*, and
|
.
X2^
= Input preset number
1 through 16. Response is three digits, padded with zeros.
