IN1806 and IN1808 Series Scaling Presentation Switchers • SIS Configuration and Control 75
Command ASCII Command
(Host to Scaler)
Response
(Scaler to Host)
Additional Description
Audio Configuration (continued)
Audio Input Name
Write name
E
I
X$
*
X1$
ANAM
}
AnamI
X$
*
X1$]
Set the name of audio input
X$
to
X1$
.
View name
E
I
X$
ANAM
} X1$]
View the name of the audio input.
Audio Output Name
Write name
E
O
X%
*
X1$
ANAM
}
AnamO
X%
*
X1$]
Set the name of audio output
X%
to
X1$
.
View name
E
O
X%
ANAM
} X1$]
View the name of the audio output.
KEY:
X$
= Audio input
1 = DP 1, 2 = HDMI 2, 3 = HDMI 3, 4 = HDMI 4, 5 = HDMI 5,
6 = HDMI 6, 7 = TP 7 (IN1808 Series only), 8 = TP 8 (IN1808 Series
only), 9 = Aux In, 10 = Mic/Line 1, 11 = Mic/Line 2, 12 = Line In 3
13 = Line In 4, 14 = File Playback L, 15 = File Playback R
X%
= Audio output
1 = HDMI 1, 2 = TP 2, 3 = Over DTP Analog, 4 = Line Out 1,
5 = Line Out 2, 6 = Line Out 3, 7 = Line Out 4
X1$
= Audio input or output name (text label) Can contain up to 32 characters, excluding: , (comma) ,*, and
|
.
Default = Audio•Input•
X!
or Audio•Output•
X@
Configure Playback
Set file-to-slot association
E
A
X8)
,<lename>CPLY
}
Assign a file to slot
X8)
. <filename>
can include an optional path.
CplyA
X8)
,<lename>
]
NOTES:
• <lename> must include the full path name if the file is not in the /Audio directory.
• The file name must include the extension. Example: song123.mp3.
• If the file is not in the /Audio directory, a / must be included in front of the name to indicate it is in the root directory.
Example: /song123.mp3.
Clear file-to slot-association
E
A
X8)
,•CPLY
}
CplyA
X8)
,•
]
Remove the audio file from slot
X8)
.
View file-to-slot association
E
A
X8)
CPLY
}
<lename>
]
View the audio file name in slot
X8)
.
Set repeat mode
E
M
X8)
*
X8#
CPLY
}
CplyM
X8)
*
X8#]
Set the audio playback repeat mode for
slot
X8)
to
X8#
.
View repeat mode
E
M
X8)
CPLY
} X8#]
View the repeat mode set for slot
X8)
.
KEY:
X8)
= Playback slot number
1 through 16
Highest priority for playback is slot 1, descending to lowest priority 16.
X8#
= Repeat play
0 = No repeat, 1 = Repeat
