XTP CrossPoint Series • Programming Guide 118
X7(
=
Port number 01 = Remote RS-232/RS-422 port
02 = Unused
03-66 = UARTs 1-64 (XTP input and output board
ports)
X8)
= Baud rate 9600 (default), 19200, 38400, 115200
X8!
= Parity O = odd
E = even
N = none (default)
M = mark
S = space
X8@
= Data bits 7, 8 (default)
X8#
= Stop bits 1 (default), 2
NOTE: X7( to X8# and X9@ are repeated on page 84 as X1% to X2).
X8$
= Port type 0 = RS-232 (default)
1 = RS-422
X8%
= Verbose mode 0 = clear or non (default for Telnet connection)
1 = verbose mode (default for RS-232 and RS-422
or USB connection)
2 = Tagged responses for queries
3 = Verbose mode and tagged for queries
NOTE: If tagged responses is enabled (modes 2 and 3), all read commands
return the constant string and the value as the set command does (for
example, the read matrix name command ECN}, returns Ipn
•
X1!]).
X8^
= Flow control H = hardware
S = software
N = none (default)
X8&
= Data pacing in MS 0000 to 1000 (0000 = default)
X8*
= Time (in 10 MS increments)
to wait for characters
10 to 32767 (for example, 10 = 100 MS)
X8(
= Time (in 10 MS increments)
between characters
2 to 32767 (2 = default)
X9)
= Priority status for receive
timeouts
0 = use the “Send” data string command
parameters if they exist (default)
1 = use the Configure receive timeout command
parameters
X9!
=
Length of message (L) or
delimiter (D)
nnnnnL = byte count (1 to 32767 or 0 = ignore byte
length, use time)
<Delimiter>D
(for example: 13D [carriage return - }])
X9@
=
Port timeout interval in 10
second increments
1 to 65000 (30 = default)
