FEC Handheld Nutrunner HFC3000 - Page 184

Chapter 9 Fieldbus I/O Interfaces
PAGE 9-4
② OUTPUT signal format [HFC3000→PLC]
The output signal is a fixed layout.
Word
Byte
Singnal Name
Connection
Contents
No.
Bit#
No.
Bit#
OUT
No.01
0
OUT
No.01
0
END
NO
Outputs when fastening operation ends.
1
1
ACCEPT
NO
Outputs when fastening result falls within set limits
2
2
REJECT
NO
Outputs when fastening result is outside of set limits.
3
3
MANREV
NO
Outputs when a manual reverse is active
Is off if RESET or PROGRAM is input
4
4
BANK OUTPUT
NO
Outputs if fieldbus message bank reshuffling BIT input is on
5
5
BATCH OK
NO
Outputs when Batch fastening is completed within set limits
6
6
Fastening Result
Data Available
NO
Outputs when fastening ends and data is available
7
7
CF ERROR
NO
With the CF option installed, Outputs when the following
conditions are true
· CF card not inserted
· CF card remaining capacity is 1% or less (~ V1.209)
· CF card remaining capacity is less than 20MB (V1.210 ~)
8
OUT
No.02
0
Work OUTPUT Bit4
NO
Outputs when corresponding Work Select 4~5 inputs ON
9
1
Work OUTPUT Bit5
NO
10
2
1ST Time Reject
NO
Outputs when fastening is outside of 1ST Time High and Low
limits
11
3
2ND Time Reject
NO
Outputs when fastening is outside of 2ND time High and Low
limits.
12
4
Work OUTPUT Bit0
NO
Outputs when corresponding Work Select 0~3 inputs ON
13
5
Work OUTPUT Bit1
NO
14
6
Work OUTPUT Bit2
NO
15
7
Work OUTPUT Bit3
NO
OUT
No.02
0
OUT
No.03
0
REJECT
NO
Outputs when fastening result is outside of set limits.
1
1
ACCEPT
NO
Outputs when fastening result falls within set limits
2
2
ABNORMAL
NO
Outputs when a system abnormal occurs.
3
3
READY
NO
Outputs when system is ready to run
4
4
BUSY
NO
Outputs during fastening or reverse operation
5
5
TQ HI REJECT
NO
Outputs when fastening torque is outside the Peak, Final, and
Sung torque High limits.
SNUG HI REJECT
6
6
TQ LO REJECT
NO
Outputs when the fastening torque is outside the Peak, and
Final torque Low limits.
7
7
PROGRAM
OUTPUT
NO
Output echo of PROGRAM input
8
OUT
No.04
0
ANG HI REJECT
NO
Outputs when the fastening angle is outside the Final and
DIFF angle High limits.
DIFF HI REJECT
9
1
ANG LO REJECT
NO
Outputs when the fastening angle is outside the Final and
DIFF angle Low limits.
DIFF LOW REJECT
10
2
RATE1 HI REJECT
NO
Outputs when the fastening rate is outside the Rate1 High
limits.
11
3
RATE 1 LO REJECT
NO
Outputs when the fastening rate is outside the Rate1 Low
limits.
12
4
RATE 2 HI REJECT
NO
Outputs when the fastening rate is outside the Rate2 High
limits.
13
5
RATE 2 LO REJECT
NO
Outputs when the fastening rate is outside the Rate2 Low
limits.
14
6
RATE 3 HI REJECT
NO
Outputs when the fastening rate is outside the Rate3 High
limits.
15
7
RATE 3 LO REJECT
NO
Outputs when the fastening rate is outside the Rate3 Low
limits.
(Continued on next page)
