Chapter 9 Fieldbus I/O Interfaces
PAGE 9-39
9-5 DeviceNet
The HFC3000 Device Net System conforms to the open field network DeviceNet. Control of tools and transaction
of message information are executed by DeviceNet Explicit message communication.
Conformance to the open field network DeviceNet System, enables connections with DeviceNet devices
(master/slave) of other manufacturers.
Also, remote I/O communication and Explicit message communication can be executed at the same time.
9-5-1 System Structure
HFC3000 DeviceNet System
Remote I/O Communication
Explicit Message Communication
DeviceNet
Slave
Station
DeviceNet Slave Stations of Other
Manufacturers
PLC (DeviceNet Master Station)
