Chapter 6 Fastening Operation
PAGE 6-12
6-2-4 Parameter Setting Mode
The following data is displayed in Fastening Parameter Display Mode. In the parameter setting
mode, “P.” is indicated at the leftmost digit of the PAR No. display and the parameter No. (01 to 32) is
indicated by the 10s and 1s digits.
The D-No. Display can be changed by pressing [▲], [▼] pushbuttons and the content of that data
No. is displayed. By pressing the [▲] or [▼] push-button, the “D-NO” can be changed ±1. The
numbers can be advanced 10 at a time by holding the [▲] or [▼] push-button longer.
Please refer to the “Parameter List” regarding parameter setting value details.
“WORK” “COUNT/D-No.” “DATA”
Fastening Method
Fastening Steps
Fastening Option
Unused
To Next Page
