Chapter 8 Options
PAGE 8-10
8-3 ID Data Input Setting
When the ID data (Part, VIN, Model No., etc.) is input before the fastening operation, the input data
is added to the fastening results and output to the HFC3000 User Console, the standard RS232C
port, and the fieldbus message data.
The selected data input method can be either by a supporting fieldbus interface (by messaging) or
the RS232C-2 serial port.
(Simultaneous input via fieldbus and the RS232C cannot be performed.)
[Precautions on ID Data Input]
･Use of ASCII code data from "0x20" to "0x7E” is possible except for the following;
"0x22", "0x27", "0x2A", "0x2F", "0x3A", "0x3C", "0x3E", "0x3F", "0x5C", "0x7C"
If other characters than above are used, there is a possibility data display is garbled or
unreadable.
･Maximum data size: Up to 32 characters(32 Byte).
If a value more than 32 bytes is sent, only the first 32 bytes are used.
･All ID data received before the fastening operation will be used (up to 32 bytes)
･Complete the data transfer before the fastening operation.
･If the ID data is input during fastening operation, it will not be accepted.
･The ID data contents are held until input of the next ID data.
･If the ID data is input after fastening operation, the ID data is overwritten.
