Chapter 4 Installation and Wiring
PAGE 4-5
4-3 Input Power Source Connection
Connect the dedicated power cable to the connector at a lower portion of the rear panel of the controller.
(A power cable is provided as standard.)
• Cable supplied for 100-120VAC power (Standard U.S. plug Style) only.
Cable over 120VAC to be supplied by customer.
