FEC Handheld Nutrunner HFC3000 - Profinet Io

Chapter 9 Fieldbus I/O Interfaces
PAGE 9-44
9-6 PROFINET I/O
The HFC3000 PROFINET I/O System conforms to the open field network PROFINET I/O. Control of tools and
transaction of message information are executed by cyclic message communication.
Conformance to the open field network PROFINET I/O System, enables connections with PROFINET I/O devices
(master/slave) of other manufacturers.
Remote I/O communication and cyclic message data communication can be executed at the same time.
9-6-1 System Structure
HFC3000 PROFINET I/O System
Cyclic Message Communication
PROFINET
IO Slave
Station
PROFINET I/O Slave Stations of
Other Manufacturers
Remote I/O Communication
PLC (PROFINET I/O Master Station)
