FEC Handheld Nutrunner HFC3000 - List of Tools

Chapter 2 Specifications
PAGE 2-4
Controller MODEL Type:
HFC-B0** -*- *- *- *
Special Data Output N:none EN:EtherNet module
CF Module N:none CF:CF Card (RS232C-2)
I/O Terminal N:none IO:I/O terminal is attached
Fieldbus Type N:No Fieldbus CC: CC-Link
DN:DeviceNet PB:ProfiBusDPV1
PI:ProfiNet I/O EI:EtherNet I/P
Controller AMP 16: 16A 24A: 24A
2-2-3 List of Tools
◆Please use the following forms of tool model and contorller type
ＨＦＴ－ Ｍ －
For any tools not indicated in the table, please contact FEC
Tool
No.
Tool Model
Maximum
Torque
[N･m]
Maximum
Rotation
Speed
[rpm]
Minimum
Rotation
Speed
[rpm]
Maximum
Rate
[N･m/deg]
Controller
4
HFT-015M50-A
15.00
1090
1
99.999
HFC-B016 / HFC-B024A
6
HFT-015M80-S
15.00
1895
1
99.999
HFC-B016 / HFC-B024A
5
HFT-025M80-A
35.00
1218
1
99.999
HFC-B016 / HFC-B024A
12
HFT-040M80-A
40.00
735
1
99.999
HFC-B016 / HFC-B024A
13
HFT-015M50-A1
15.00
1215
1
99.999
HFC-B016 / HFC-B024A
15
HFT-025M80-A1
25.00
1070
1
99.999
HFC-B016 / HFC-B024A
16
HFT-040M80-A1
40.00
648
1
99.999
HFC-B016 / HFC-B024A
7
HFT-060M80-A
60.0
446
1
99.999
HFC-B016 / HFC-B024A
19
HFT-080M80-A
80.0
330
1
999.99
HFC-B016 / HFC-B024A
8
HFT-130M80-A
130.0
203
1
999.99
HFC-B016 / HFC-B024A
14
HFT-015M80-S1
15.00
1600
1
99.999
HFC-B016 / HFC-B024A
18
HFT-040M80-S
40.00
694
1
99.999
HFC-B016 / HFC-B024A
11
HFT-040M80-T
40.00
694
1
99.999
HFC-B016 / HFC-B024A
27
HFT-015M50-P1
15.00
1190
1
99.999
HFC-B016 / HFC-B024A
30
HFT-035M80-P1
35.00
778
1
99.999
HFC-B016 / HFC-B024A
Tool Shape
Ｓ：Straight Ａ：Angle
Ｔ：T-Type Ｐ：Pistol
Ｌ：L-Type Ｄ：Driver
Motor Type
５０：45W １２０：120W
８０：70W
８１：
Maximum Torque
