Chapter 4 Installation and Wiring
PAGE 4-4
Mounting (Spacing)
For safe removal of the Controller,
install with spacing of 10mm or more (side to side)
Caution
100mm or more
10mm
or
more
10mm
or
more
250mm or more
Upper
Lower
250mm or
more
