Chapter 6 Fastening Operation
PAGE 6-3
(1) Controller Operation / Check Buttons
①CAL Button: CAL voltage check
When this button is pressed, a full scale calibration check of the tool torque transducer tool is
performed.
The calibration torque value is indicated in the “DATA” section of the display.
If as a result of the check, the value is within the specified ranges, the status LED on the tool flashes
alternately in green <--> orange.
If as a result of the check, the value falls outside the specified range, the status LED on the tool flashes
alternately in red <--> orange.
②RST Button
Used to reset the controller.
When this is pressed during fastening, the fastening is interrupted and all output signals are reset.
Additionally, the zero voltage of the torque transducer is checked and indicated (in the DATA display)
The RST button also resets the REJECT buzzer and any ABNORMAL condition from the controller.
③PRG Button: RUN / Program selection Button
Depressing this button for longer than 1.5 seconds, changes the operation mode from Run to Program
(or from Program to Run alternately).
(2) Indication LEDs
①OK LED Green [QL OK]
Lights when the fastening ends with all results within the various programmed setting limits.
When the TOTAL OK LED lights up, this LED is OFF.
②NG LED Red [NG]
Lights when the fastening ends with a result falling outside any of the various programmed setting limits.
Additionally, lights when a system Abnormal occurs (The abnormal code is displayed on the data
display).
③TOTAL OK LED Green [TOTAL OK]
Lights when the results of the fastening operations are all acceptable, the designated number of times
(cycle count).
④TORQUE LED Green [TORQUE]
Lights when the DATA content being displayed is a torque value.
⑤ANGLE LED Green [ANGLE]
Lights when the DATA content being displayed is an angle value.
(3) Buttons for Data viewing / Selection Operations
①SET key
This is used to finalize an indication or finalize data entered into memory.
②Cursor keys [▲][▼]
Used to scroll the data cursor and to change preset data.
Used to change the WORK No. in the run mode mode.
(Buttons cannot be used if an abnormal condition exists.
③Cursor keys [◄][►]
Used to change the display mode and to move the data cursor.
