Chapter 6 Fastening Operation
PAGE 6-25
4. Fastening Time High Limit Judgment
1ST Time High limit Reject
Cause: Non-engagement / broken socket, no fastener present
2ND Time High limit Reject
Cause: Fastener is yielding, fastener is cutting
threads, socket disengaged
5. Rundown Revolutions High Limit Judgment
Rundown Revolutions High Limit Reject
Cause: Bolt length wrong, socket disengaged
Start trigger Off Reject
Cause: Start Trigger was released before the end
of fastening
Gyro Stop Reject
Cause: Gyro sensor swing detection detected a
safety Stop
