Ex planations of vibration and shock – severity level
Severity level 1
(SL1, as per IEC/EN 60068,
part 2 – 29)
Vibration:
0.15 mm path at 10 … 58 Hz;
2 g acceleration at 58 … 150 Hz
Shock:
±15 g at 11 ms duration;
5 shocks per direction
Continuous shock:
±15 g at 6 ms duration;
1000 shocks per direction
Severity level 2
(SL2, as per IEC/EN 60068,
part 2 – 27)
Vibration:
0.35 mm path at 10 … 60 Hz;
5 g acceleration at 60 … 150 Hz
Shock:
±30 g at 11 ms duration;
5 shocks per direction
Continuous shock:
—
Tab . A.5 Technical data: explanation on vibration and shock resistance (severity level)
