Festo MPA-S - Separating the MPA-S Valve Terminal from the CPX Terminal

B Supplementary component overview
Festo – P.BE-MPA-E N – 1309f – English 161
B.2 Separating the MPA-S valve terminal from the CPX terminal
The valve terminal MPA-S is connected to the CPX terminal through a port pattern (  Fig. B.1).
1
23
1 CPX terminal
2 Port pattern
3 Valve terminal MPA-S
Fig. B.1 Port pattern
