3 Mounting and installation
48 Festo – P.BE-MPA-EN – 1309f – English
3.1 General instructions on mounting and dismantling
Special information on replacing or adding pneumatic components can be found in
chapter 5.
– Information on mounting the MPA-S valve terminal with CPX terminal can be found in
the CPX system manual.
– Information on dismounting and mounting of I/O modules is provided in the I/O mod-
ule description ( system description for your CPX terminal, table “Descriptions for
the CPX terminal”).
– Information on mounting modules and c omponents ordered at a later stage can be
found in the pa ckage insert.
Warning
Accidental movements of the connected actuators and disconnected tubing lines can
cause injury to persons and/or material damage.
Before carrying out mounting, installation and maintenance work, switch off the follow-
ing:
– Compressed air supply
– Operating and load voltage supplies.
Note
Handle all modules and components of the MPA-S valve terminal with c are. Make sure
that the specified torques are complied with.
Electrostatically sensitive devices:
Do not touch any electrical or electronic components.
