A Technical appendix
148 Festo – P.BE-MPA-EN – 1309f – English
Cert ifications
CE marking ( see declaration of conformity)
www.festo.com
to EU EMC Directive
– Emitted interference
1)
– Immunity to interference
2)
1) The MPA-S valve terminal is intended for use in an industrial environment. Outside of industrial environments, e.g. in commercial
and mixed-residential areas, actions to suppress interference may have to be taken.
2) The maximum signal cable length for the MPA-S valve terminal with multi-pin plug connection is 10 m
Tab. A.13 Technical data: certifications
A.1.4 Electrical data
MPA-F v alve terminal with multi-pin plug conn ection:
– The maximum number of sub-bases that can be co nfigured corresponds to th e num-
ber of addresses available. The maximum number of solenoid coils which can be actu-
ated is limited by the multi-pin plug connection to 24 addresses.
MPA-S valve terminal with CPX terminal:
– A maximum of 16 sub-bases (MPA-S with electric supply plate) or 8 sub-bases (MPA-S
without electric supply plate) are permitted.
General
Protection against electric shock
(protection against direct and indirect
contact in accordance with I EC/EN 60204-1)
Through t he use of PELV circuits (Protected Ext ra-Low
Voltage)
Tab. A.14 Electrical data: general
MPA-S valve terminal with multi-pin plug connection or AS-interface
Power supply
Nominal voltage 24 V DC ±25 %
Residual ripple 4Vpp
Curre nt consumption per pin at the sub-D
multi-pin plug connection (for each valve solenoid
coil) at 24 V
MPA1 MPA2
Nominal pick-up current/duration 80 mA/25 ms 100 mA/30 ms
Nominal current with current reduction 2 5 mA af ter 25 ms 20 mA after 30 ms
Tab . A.15 Electrical data: MPA-S v alve terminal with multi-pin plug connection
Technical data on electric components of the MPA-S v alve terminal with multi-pin plug
connection or AS-interface can be found in the respective package insert.
