Festo MPA-S - Pressure Sensor Plate

2Overview
Festo – P.BE-MPA-E N – 1309f – English 43
2.6.1 Pressure sensor plate
The pressure sensor plate has the following display elements:
1
2
3
4
5
1 Pressure sensor plate
2 Red LED: pressure exceeded
3 Green LED: pressure maintained
4 Red LED: pressure not reached
5 Red LED: common error display
Fig. 2.19 Display components of the pressure sensor plate
