4 Commissioning
92 Festo – P.BE-MPA-EN – 1309f – English
Note
The manual override cover c aps serve to limit the function of the manual override and
are constructed so that they can only be removed with an increased exertion of force.
During dismantling, the snap hooks of the cover will be damaged.
4.4.2 Dismounting
Proceed as follows:
• Use a suitable screwdriver to lift the manual override coverer caps from the manual override
( Fig. 4.4):
Fig. 4.4 Dismounting the manual override cover caps
