B Supplementary component overview
160 Festo – P.BE-MPA-EN – 1309f – English
Proportional pressure regulator VPPM-…TA-...
+w
-w
3
1
2
x
Ident. code: QA, QB, QC, QD, QE, QF, QG, GH, GK,
QL, QM, QN
Function:
– Regulates the pressure proportional to a
specified nominal value
Tab. B.6 Proportional pressure regulator
Ver tical pressure shut-off plate VMPA1-HS
4
2
33
82/84
51
3
12/14
12/14
Ident. code: PS
Function:
– Permits a valve c hange under operating and
pilot pressure
Tab. B.7 Vertical pressure shut-off plate
